5 Direction Navigation Rocker Joystick Button Module

$0.5500

In stock:14,820

Volume discounts:

+100 5 % $0.5200
+300 7 % $0.5100
+500 11 % $0.4900
+1000 13 % $0.4800

- +

Add to Cart

Ships in 2-3 business days, then:

Free delivery in 10-15 days by YunExpress on orders over $35.

Free delivery in 5-7 days by DHL on orders over $200.

More shipping info

Custom circuit boards available upon request. Please Contact customer service

All Info 詳細

詳細

説明
Easily navigate control panels etc. with this small form factor joystick module. This a five direction navigation button module, already placed on a breakout board for your convenience.

特徴
Number of IO pins: 7
Operating voltage: 2.0V-9.0V
Operating temperature: -40° Celsius to +85°
ピンの説明
COMï¼šCommon ï¼ŒVCC or GND connected to the MCU development board
Up direction buttonï¼šConnect to IO pin of the MCU
DWNï¼šDown direction buttonï¼ŒConnect to IO pin of the MCU
LFT: Left direction button, Connect to IO pin of the MCU
RHT: Right direction button,Connect to IO pin of the MCU
MID: Middle direction button, Connect to IO pin of the MCU
SET: Set button, Connect to IO pin of the MCU
RST: Reset button, Connect to IO pin of the MCU
