AD2S1210ASTZ

If you’re designing precise motion control systems, like servo drives, robotics, or aerospace applications, the AD2S1210ASTZ RDC chip is perfect for you.

Its 16-bit resolution divides each rotation into 65,536 precise steps, giving extremely smooth and accurate positioning. It has an integrated excitation generator (adjustable from 2kHz to 20kHz), simplifying your circuit and wiring.

It supports both parallel and serial outputs, so connecting it to your microcontroller or PLC is easy. The chip also includes a dedicated speed register, ideal for closed-loop motor control. Plus, built-in fault detection ensures you quickly spot any signal issues.

Its LQFP-48 package is compact, SMT-friendly, and works reliably from -40°C to +125°C, ideal for industrial environments.

AD2S1210ASTZ Pinout Diagram

AD2S1210ASTZ Equivalent Resolver Converter

If you’re considering replacements for the AD2S1210, keep this in mind: AD2S1210-EP is for harsh environments like military and aerospace, with wider temperature range (–55°C), higher cost, and longer lead times. AD2S1210ESZ has identical functionality but lacks automotive-grade certification, fine for industrial use but not recommended for automotive. All these models share identical footprints and pinouts, allowing easy swaps. Just double-check your project’s certification needs before picking.

AD2S1210ASTZ Resolver Interface Circuit

When connecting a Resolver to the AD2S1210, remember this analog front-end circuit. Series resistors (1kΩ) and clamping diodes protect inputs. Simple RC filters remove noise for stable readings. Optional 2.5V bias centers signals if needed. For long-distance wiring, a differential termination resistor RA improves signal integrity.

AD2S1210ASTZ Motor Encoder Application

When using the AD2S1210 in servo systems, it converts resolver signals into precise digital angle and speed data, replacing traditional encoders. It’s highly resistant to interference, perfect for harsh conditions (high temperature, vibration, EMI). With up to 16-bit accuracy and built-in speed calculation, it greatly simplifies control tasks. Ideal applications include robotics joints, CNC machines, EV motor drives, and aerospace equipment.

AD2S1210ASTZ Position Feedback Wiring

When using AD2S1210ASTZ for motor position feedback, resolver outputs (SIN/COS) connect directly to the chip’s differential inputs. The EXC pin provides excitation (usually 6.25–10kHz). Use simple RC filters for input protection. The chip converts signals to digital angle data sent via SPI or parallel to your MCU/DSP for precise control. Connect RESET for initialization, LOS/DOS pins detect signal faults.
