CD4011BE datasheet, pinout & application
- Logic Type: NAND Gate
- Number of Circuits: 4
- Number of Inputs: 2
- Package: 14-PDIP
FREE delivery for orders over HK$250.00
Quick response, quick quotaton
Flash shipment,no worries after sales
Original channel,guarantee of the authentic products
CD4011BE electronic component
CD4011BE Pinout
1：Overview of the CD4011BE:
CD4011BE is a four-channel 2-input NAND gate circuit chip. Each output part of CD4011BE is equipped with a buffer, which greatly improves the ability to resist interference and can reduce the output impedance.
CD4011BE adopts DIP14/SOP14 packaging form. It has the characteristics of low power consumption and high noise tolerance. CD4011BE can work in-55 C to +125 C. It is widely used in scenarios such as password locks and counters.
2：CD4011BE Important pin function definition:
| Pin | NAME | DESCRIPTION | Pin | NAME | DESCRIPTION |
|---|---|---|---|---|---|
| 1 | I₁ | Input I₁ | 8 | I₅ | Input I₅ |
| 2 | I₂ | Input I₂ | 9 | I₆ | Input I₆ |
| 3 | O₁ | Output O₁ | 10 | O₃ | Output O₃ |
| 4 | O₂ | Output O₂ | 11 | O₄ | Output O₄ |
| 5 | I₃ | Input I₃ | 12 | I₇ | Input I₇ |
| 6 | I₄ | Input I₄ | 13 | I₈ | Input I₈ |
| 7 | VSS | VSS | 14 | VDD | VDD |
