RHRP8120 | Equivalent Models onsemi

Explore the equivalent options to the RHRP8120, providing similar performance and reliability. Access the Reference manual to compare specifications, features, and find the best price for your needs.

Brands: onsemi

Download: RHRP8120 Datasheet PDF

Price: inquiry

In Stock: 1,297

Voltage-DCReverse(Vr)(Max): 1200 V

Current-AverageRectified(Io): 8A

Voltage-Forward(Vf)(Max)@If: 3.2 V @ 8 A

Package: TO-220-2

FREE delivery for orders over HK$250.00

Quick response, quick quotaton

Flash shipment,no worries after sales

Original channel,guarantee of the authentic products

RHRP8120 Equivalent

RHRP8120 Equivalent

RHRP8120 Equivalent PINOUT

RHRP8120 Equivalent Pinout

The following table lists the equivalent components for the RHRP8120, a high-efficiency rectifier diode from ON Semiconductor. These alternatives are compared based on key parameters such as peak repetitive reverse voltage, average forward current, max forward voltage, and package type.

Parameter	RHRP8120 (onsemi)	DHG10I1200PA (IXYS)	DSEP8-12A (IXYS)	VS-8ETU12HN3 (Vishay)	STTH812G (ST)
Average Rectified Current (IF(AV))	8 A	10 A	8 A	8 A	8 A
Reverse Voltage (VRRM)	1200 V	1200 V	1200 V	1200 V	1200 V
Forward Voltage (VF)	3.2 V @ 8 A	2.0 V @ 10 A	1.7 V @ 8 A	1.7 V @ 8 A	1.7 V @ 8 A
Reverse Recovery Time (trr)	70 ns	35 ns	35 ns	35 ns	35 ns
Peak Surge Current (IFSM)	100 A	100 A	100 A	100 A	100 A
Package Type	TO-220AC	TO-220AC	TO-220AC	TO-220AC	TO-220AC
Operating Temperature Range (Tj)	-65°C ~ 175°C	-55°C ~ 150°C	-55°C ~ 150°C	-55°C ~ 150°C	-55°C ~ 150°C
Discontinued	Yes	No	No	No	No

Recommendation:

If you’re looking for alternatives that are close to the RHRP8120, DSEP8-12A (IXYS) and VS-8ETU12HN3 (Vishay) are solid choices. They share similar packaging, reverse voltage, and average current specifications, with DSEP8-12A offering slightly lower forward voltage at 8A and faster reverse recovery time.

If your application requires higher current, the DHG10I1200PA (IXYS) offers a higher current rating of 10A, making it more suitable for high-current applications.
