TL062CP pinout & equivalent | substitute onsemi
- Amplifier Type: J-FET
- Number of Circuits: 2
- Output Type: -
- Package: 8-DIP (0.300, 7.62mm)
FREE delivery for orders over HK$250.00
Quick response, quick quotaton
Flash shipment,no worries after sales
Original channel,guarantee of the authentic products
What does a TL062 Op-Amp with output grounded and both inputs connected together with voltage…
TL062CP Pinout
The TL062CP is a low-power, dual JFET-input operational amplifier housed in an 8-pin DIP package. It is well-suited for applications requiring high input impedance and low supply current, such as battery-operated analog circuits and sensor signal conditioning. The following table outlines the pin configuration of the TL062CP to assist with proper integration into electronic designs.
| Pin Number | Pin Name | Description |
|---|---|---|
| 1 | 1OUT | Output of Op-Amp 1 |
| 2 | 1IN− | Inverting input of Op-Amp 1 |
| 3 | 1IN+ | Non-inverting input of Op-Amp 1 |
| 4 | VCC− | Negative power supply (ground in single-supply use) |
| 5 | 2IN+ | Non-inverting input of Op-Amp 2 |
| 6 | 2IN− | Inverting input of Op-Amp 2 |
| 7 | 2OUT | Output of Op-Amp 2 |
| 8 | VCC+ | Positive power supply |
Understanding the TL062CP pinout is essential for designing efficient analog signal processing circuits. With its two independent op-amps and straightforward pin layout, this device offers reliable performance in compact form, supporting low-power and high-impedance applications.
