DB107 Bridge Rectifier | Datasheet, Circuit & Price | Pinout

DB107 DIP-4 Mini bridge rectifier 1A1000V electronics parameter ASEMI

DB107 Pinout

DB107 Pinout Diagram

The DB107 is a bridge rectifier, designed to convert alternating current (AC) into direct current (DC). It consists of four pins that serve different functions for the input and output connections. The device allows for the efficient transformation of AC power into usable DC power for various electronic applications. Below is the pinout description for the DB107, detailing each pin’s role in the rectification process.

The DB107 bridge rectifier provides an efficient solution for converting AC to DC. The pinout configuration ensures that the correct polarity is achieved for both the input and output connections, making it an essential component for power supply circuits. Understanding its pinout is crucial for proper installation and application in electronic systems.
